Granuliform supplies transporting and delivering auger screw feeder

    Buy cheap Granuliform supplies transporting and delivering auger screw feeder from wholesalers

    Buy cheap Granuliform supplies transporting and delivering auger screw feeder from wholesalers
    • Buy cheap Granuliform supplies transporting and delivering auger screw feeder from wholesalers

    Granuliform supplies transporting and delivering auger screw feeder

    Ask Lasest Price
    Brand Name : hongyuan
    Model Number : XL-100-6
    Certification : ISO
    Price : US$650-1550 per set
    Payment Terms : T/T or By Alibaba Trade Assurance:100% full amount in advance
    Supply Ability : Machine in stock
    Delivery Time : Within 2 days after getting the money
    • Product Details
    • Company Profile

    Granuliform supplies transporting and delivering auger screw feeder

    Granuliform supplies transporting and delivering auger screw feeder

    Product Application

    Granuliform supplies transporting and delivering auger screw feeder is specially for rural transport, loading, pour the crib, storage equipment, and design a small has small volume, light weight, easy to move, grain, high efficiency, lower breakage, occasions, widely used, safe and reliable characteristics, very suitable for individual farmers, food profession and agricultural cooperatives.Also can be used for farms, feed mills, food factory, plastics factory conveying makings of the occasion.May transport wheat, soybean, corn, rice, sorghum, plastic, resin, rice and other grains.Can be horizontal, oblique way transmission.

    Working Performance

    Specifications

    Model No.Length (Meters)Pipe diameter

    Loading

    Capacity(t/h)

    Motor phase-power(kw)InstallationStructureConveying height
    XL-100-66100mm5-8

    Single phase

    -220V-3kw

    Vehicle mountedSteel screw blade inside3-4m
    XL-100-88100mm5-8

    Single phase

    -220V-3kw

    Vehicle mounted


    Steel screw blade inside3-4m
    XL-100-1010100mm5-8

    Single phase

    -220V-3kw

    Vehicle mountedSteel screw blade inside3-4m
    XL-100-1212100mm5-8

    Single phase

    -220V-3kw

    Vehicle mountedSteel screw blade inside3-4m
    XL-160-66160mm15-20

    Three phase

    -220V-4kw

    Vehicle mountedSteel screw blade inside3-4m
    XL-160-88160mm15-20

    Three phase

    -220V-4kw

    Vehicle mountedSteel screw blade inside3-4m
    XL-160-1010160mm15-20

    Three phase

    -220V-4kw

    Vehicle mountedSteel screw blade inside3-4m
    XL-160-1212160mm15-20

    Three phase

    -220V-4kw

    Vehicle mountedSteel screw blade inside3-4m

    Detailed Images


    Material

    Soft spiral is to adopt a kind of manganese steel, the British imported material, hardness, elasticity, abrasion resistance is good, and smooth outer edge through special processing, won't cause harm to the pipe, the pipe is premium PVC material, keep elastic, all the year round can be arbitrary curve.And add the wear and extend the life of the pipe.


    Related Products

    Test Running

    1. According to the packing list by piece count, check the parts are complete after opened the box.
    2. When commissioning, the tube should try to keep nature, try to make the pipe smooth turning and to prevent wear pipe.
    3. When debugging, flexible screw conveyor machine should use the international 4 square power cord.
    4. When Installing the V-belt of motor, it should set the small wheel first, then set the big wheel.
    5. Don’t racing the engine while the machine working, to prevent wear the pipe.
    6. In the process of flexible screw conveyor machine installed to the truck, the machine head should be outward installation and then use the screw bolt to fix it.
    7. If the material clogging while working should immediately shut down, clean up and then restart.
    8. If the blade damaged in the process of using, you can use welding machine to weld.

    Special Notes

    Please do not let Granuliform supplies transporting and delivering auger screw feeder running without loading; Please do let the machine running with loading; Please do not let the machine do the idling running.Tube bending radius should not be less than 1 meter, pipe extrusion or deformation caused by the sharp weapon damage or sag.Equipment no-load idling is forbidden.Keep the host under 50 cm pipe in vertical state.

    Packing & Delivery

    Packing in Plywooden Box

    Packing Size:1200*1200*500mm

    Gross Weight: 180kgs


    Please kindly tell us the following answers when you send us inquiry:

    1. What kind of grain do you need to process?

    2. What is your capacity per hour?

    3. What is your local electricity?


    For more information on Granuliform supplies transporting and delivering auger screw feeder contact us freely by:

    E-mail: cnhongyuan at chinavibratingscreen.com

    Mob/Whatsapp/Wechat: +8615560250277

    Skype: zhu.sunshine

    QQ: 70752106

    Website: www.chinavibratingscreen.com

    Website at Alibaba: hongyuanzd.en.alibaba.com

    Name:Grace
